Patio de las Jacarandas at Aguascalientes, Mexico

Patio de Las Jacarandas is a Jan Hendrix and Hendrix Studio-designed work of public art in Aguascalientes, Mexico. The project’s metal canopy was developed and fabricated by Zahner in water-jet cut aluminum.

Situated at the historic Plaza de la Patria in Aguascalientes, the Patio de las Jacarandas is an architectural open-air canopy. Arturo Revilla and Jose Luis Jimenez Garcia served as the project’s architects, while Zahner’s scope on the project centered around the engineering and fabrication of the art canopy.

The system was engineered and tested by Zahner, and then manufactured and delivered to the jobsite where local installers erected the screen wall. The project was completed in 2015, and features a two-tiered canopy of water jet-cut aluminum plates. Both layers of cut-out metal are painted to create the white ¼” aluminum plate.

Canopy Filtered Shading with Diaphanous Light

Two layers of waterjet cut artwork make up the roof of the Aguascalientes canopy. The first layer, suspended on the bottom of the canopy, shows the overlapping branches of the jacaranda tree. The second layer of cutout leaves is installed 16” above the lower ceiling canopy.

These two layers are held apart from one another using tension cables. The distance between each layer gives the illusion of peering through tree branches. Intriguing shadows are also created, offering an immersive, shaded area for pedestrians in the city square to rest beneath.

The canopy’s two layers are designed to evoke the jacaranda tree at different seasons of the year. This motif was selected by the artist due to its prevalence in Aguascalientes. Numerous jacarandas are planted in parks and public areas across the City of Aguascalientes as well as throughout central Mexico. Their blooms are heralded as a symbol of the beginning of the spring season, blooming in February.

Creating the Cut Plate Material

To accommodate the intricate lines, the artwork is fairly thin in some areas, ¼” aluminum plate was used to water jet-cut the desired pattern. Using plate material gives extra support for artwork, and keeps delicate lines from bending or becoming misshapen as the public interacts with the art.

Jan Hendrix supplied Zahner with models, sketches, and finished drawings of the artwork. Zahner team of design engineers translated the artwork into files for manufacturing and cutting the metal shapes out of the aluminum plate. After the cutting process was completed, the panels and structural components were painted white and sent to the job site in Mexico for installation.

Unique Column Design for Patio de Las Jacarandas
